Test, Repair and Recalibration of Heidenhain RON 350/2048 encoder for Siemens Spindle motor
EEC visited a customer on-site to test, repair and recalibrate a HEIDENHAIN RON 350/2048 encoder, with great savings to the end user over a new replacement encoder. HEIDENHAIN products carry a long service life and parts availability, translating to longevity of machine tool investments for machining companies.
The HEIDENHAIN RON350 2048 (RON 350 2048) Encoder is a HEIDENHAIN sealed angle encoder from the RON 350 series with 17mm tapered hollow shaft diameter dimensions with integrated bearing. The HEIDENHAIN RON350 encoder photoelectrically scans pure binary patterns on a glass graduated disk to determine the position value. RON350 has a resolution of 2048 pulses/rev. These sealed angle encoders are usually fitted on a SIEMENS Motor with the internal P/N SIEMENS 519.30453.01.
Heidenhain RON 350/2048 encoder Repair & Calibration Work
PCB board for identification and fault finding
Side view old dirty faulty encoder, label missing, not so easy to identify
Bottom view with cable exit
Internal encoder insides, also showing mechanical taper and Siemens motor connector
Internal PCB board for testing and recalibration
